Should You Install a Pedestal Sink?
Pedestal sinks free up floor space, make tight bathrooms feel larger, and showcase timeless style. Yet many Toronto homeowners avoid the upgrade because rough-in pipes, blocking, and wall anchors must be perfect. In this 2025 guide by ANTA Plumbing, you’ll learn the exact tools, code-compliant rough-in heights, and step-by-step sequence to swap out a bulky vanity for a sleek pedestal sink—usually in a single day.Tools & Materials Checklist
Tool | Why You Need It |
Adjustable wrench & basin wrench | Tighten supply nuts in cramped spots |
Compact tubing cutter / PVC saw | Trim copper or ABS drain precisely |
Level & tape measure | Confirm basin is square and rough-in is on-center |
Pencil, painter’s tape, stud finder | Mark wall blocking and anchor holes |
2″x 8″ blocking (pre-cut) | Code-approved backer for lag screws |
Faucet kit, pop-up drain, P-trap | Most basins ship without traps or supply lines |
Silicone sealant & plumber’s putty | Seal pop-up flange and faucet base |
Toronto Tip: A building permit is required if you move supply or drain lines, because it’s considered a “material alteration” under the Building Code Act toronto.ca.
Planning & Rough-In Requirements
Target rough-in dimensions (standard basins):
- Drain stub-out height: ~18–19 in. above finished floor
- Supply stub-outs: ~21 in. above floor, 4–6 in. left/right of center homedepot.comthespruce.com
- Blocking height: Basin mounting holes usually 30–32 in. high—install 2×8 blocking before drywall.
Code notes:
- Ontario Code requires fixture drains to slope ¼ in. per foot to the stack..
- All fixtures must vent properly; if the trap arm exceeds 1.5 m, add an AAV or vent tee (Part 7, OBC).
- Floors around plumbing fixtures must be “reasonably impervious to water” toronto.ca.
Step-by-Step Pedestal Sink Installation
1 Shut Off & Demo
- Close the bathroom shut-offs; if none exist, shut off the home’s main valve.
- Disconnect the vanity supply lines and trap; cap the stubs.
2 Prep Drain & Supply
- Using a compact cutter, trim copper or PEX flush to 3 in. beyond wall.
- Clean burrs and sand; solder new ½-in. sweat ells or attach push-fit adapters.
- Dry-fit a 1¼-in. ABS elbow so its center is on the basin centerline (Family Handyman method) familyhandyman.com.
3 Install Wall Blocking
- Locate studs; cut drywall slot if needed.
- Screw 2×8 block between studs at basin-hole height; patch with moisture-resistant board.
4 Set Pedestal & Mark Anchor Holes
- Slide pedestal against wall; set basin on top.
- Level front-to-back and side-to-side; shim pedestal foot if floor is uneven.
- Mark through basin anchor holes onto wall; mark pedestal base on floor.
5 Mount Faucet & Pop-Up on Workbench
- Insert faucet stems with O-rings or plumber’s putty if none supplied.
- Tighten tailpieces; install pop-up drain with a bead of putty under flange.
6 Anchor Basin & Pedestal
- Drill ¼-in. pilot holes into blocking; drive 3-in. stainless lag screws with fender washers.
- Apply a thin silicone bead where basin meets wall for extra support.
7 Connect P-Trap & Supplies
- Cut the tailpiece to length; connect P-trap so it lines up without strain.
- Attach braided stainless supply lines; open stops and flush debris.
8 Pressure & Leak Test
- Run warm water for two minutes; inspect all joints.
- Check floor and wall seams for seepage; re-level if the basin settles.
Toronto-Specific Plumbing Code Tips
Requirement | Detail |
Permit | Needed if relocating drains/vents or adding new shut-offs toronto.ca |
Venting | Trap arm to vent ≤ 1.5 m, fall ≥ 6 mm/m (OBC Part 7) |
Clearance | 750 mm min. from sink’s center to side wall/adjacent fixture homedepot.com |
Moisture protection | Waterproof floor within basin footprint toronto.ca |
Install Pedestral Sink – Common DIY Errors & Fixes
Mistake | Prevention |
Mis-centering drain by 1–2 in. | Dry-fit pedestal and mark BEFORE gluing elbows |
Skipping wall blocking | Basin lags will crack drywall—always install 2×8 support |
Over-tightening supply nuts | Hand-tight + ¼ turn stops leaks without crushing gaskets |
Forgetting escutcheons | Cover rough copper/PEX for a finished look |
Pedestal Sink Installation Cost & Time Expectations
Scenario | DIY (CAD) | Pro Install (CAD) |
Basic swap, no pipe move | $250–$400 parts+permit | $600–$850 labour |
Re-route drain/supply | $400–$650 | $1,200–$1,600 incl. permit |
A well-planned DIY takes 6-8 hours. Factor extra time for drywall or tile repair.
When to Call ANTA Plumbing
- Drain needs to move more than 2 in.
- Vent re-routing or AAV install required.
- Lead, galvanized, or non-standard pipe sizes present.
- You want permit handling and warranty protection.
Book a Professional Pedestal Sink Install →
Frequently
Asked Questions
Yes. Drain and supplies must align with the slender pedestal; offset pipes require relocation.
Aim for 18–19 in. above finished floor, centered behind pedestal
Only if existing pipes align perfectly and blocking is already present; otherwise drywall access is inevitable.
Moving any drain or vent typically needs a plumbing permit
Precise measurements—“If one mark is off, you throw out the plumbing,” says ANTA master plumber.
The line color style will help you to highlight the content in the accordion. It will also enable you to create a difference between the content of the accordion and the general content. Line color style of our widget will bring elegance along with simplicity in your web page.
Key Takeaways
- Precise rough-in is critical; verify centerlines before cutting pipes.
- Wall blocking supports heavy vitreous-china basins.
- Ontario Code compliance avoids inspection failures.
- DIY is possible in one day for straightforward swaps—call a pro for pipe moves.
